657-GBX564LCKold-DraftModel GBX564LC
Product specification

Kold-Draft GBX564LC 42 5/16" Full Cube Ice Machine Head - 543 lb/24 hr, Water Cooled, 208-230v/1ph

Kold-Draft GBX564LC 42 5/16" Full Cube Ice Machine Head - 543 lb/24 hr, Water Cooled, 208-230v/1ph — image 1 of 2

Image 1 of 2

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Enter a whole number from 1 to 10,000.

Adds this item to your quote list. Pricing and fulfillment details are confirmed when we quote.

The Kold-Draft GBX564LC X-Series ice machine head delivers 543 lbs of crystal-clear, full-cube ice daily with water-cooled efficiency. Ideal for commercial kitchens needing high-performance, low-maintenance ice production.

Key features

  • 01543 lbs (456 lbs AHRI-certified) of **full-cube ice daily** - ideal for cocktails, beverages, and hospitality applications
  • 02Water-cooled **self-contained condenser** eliminates external water tanks, saving space and reducing maintenance
  • 03Durable **300-series stainless steel exterior** with a **plastic top and louvers** for a balance of strength and functionality
  • 04Crystal-clear ice production with an **upside-down horizontal evaporator** that removes particulates for premium-quality ice
  • 05**LCD display** and **thermostatic expansion valve** for real-time monitoring and optimal refrigerant control, minimizing downtime

Description

The Kold-Draft GBX564LC X-Series ice machine head is a high-performance solution for commercial kitchens and restaurants seeking premium, full-cube ice production. With a 543 lb (456 lb AHRI-certified) daily capacity, this water-cooled unit ensures consistent, crystal-clear ice ideal for cocktails, beverages, and hospitality applications. Its self-contained condenser and horizontal evaporator design eliminate the need for external water tanks while maintaining optimal cooling efficiency. The 300-series stainless steel exterior and plastic top with louvers balance durability and functionality, making it a reliable workhorse for high-demand environments. Featuring a thermostatic expansion valve and LCD display, operators can monitor performance and adjust settings effortlessly, ensuring minimal downtime and maximum productivity. Whether you're outfitting a full-service restaurant, bar, or catering kitchen, the GBX564LC delivers slow-melting, full-cube ice that enhances drink presentation while meeting the rigorous demands of professional settings. Its water-cooled design also reduces energy costs compared to air-cooled models, making it a smart investment for facilities prioritizing efficiency. With a 5-year compressor and evaporator warranty and 3-year parts & labor coverage, this Kold-Draft ice machine head offers long-term peace of mind for businesses that can't afford ice production interruptions. Suggested for 208-230v/1-phase power, this unit is built to integrate seamlessly into existing commercial kitchen setups, providing a hassle-free upgrade for restaurants, hotels, and foodservice operations.

Specifications

Manufacturer
Kold-Draft
24 Hr. Production (lb)
543
Compressor Type
Water Cooled
Depth (in)
25.63
Height (in)
17
Ice Type
Full Cube
Phase
1
Product
Ice Machine Heads
Product Type
Ice Makers & Bins
Rating
Better
Refrigerant
R404A
Series
X
Suggested Use
Commercial
Voltage
208/230
Warranty
3-year Parts & Labor 5-year Parts for Compressor & Evaporator
Water Inlet (in)
0.75
Width (in)
42.3
Weight
185.00

Details

  • 01543-lb. maximum ice production capacity
  • 02456-lb. AHRI-certified ice production capacity
  • 03Large-cube ice size: 1.25 in. x 1.25 in. x 1.25 in.
  • 04Full cube ice melts slowly, which is ideal for drinks intended to be sipped
  • 05Water-cooled, self-contained condenser
  • 06Upside-down horizontal evaporator and water plate assembly produces crystal-clear full-size cubes
  • 07Exterior is constructed of 300 series stainless steel
  • 08Top and louvers are made of plastic
  • 09LCD display provides a way for operators to check on the machine
  • 10Refrigeration system has a thermostatic expansion valve for controlling refrigerant
  • 11Rounded corners prevent injuries
  • 12Part of the X-Series and is stackable with other units
  • 13Uses R404A refrigerant
  • 146,500 average BTU; 8,750 maximum BTU
  • 15Bin sold separately
  • 16Required water temperature: 45-90 degrees F
  • 17Required potable water pressure: 20-100 PSIG
  • 18Required ambient air temperature: 45-110 degrees F
  • 19Requires 4 in. on the left side, 8 in. on the right side and back, and 6 in. on top for clearance
  • 203⁄4-in. FPT potable water inlet
  • 213⁄4-in. FPT bin drain
  • 223⁄4-in. I.D. flex tubing cuber drain
  • 233⁄8-in. FPT condenser inlet
  • 241⁄2-in. FPT condenser outlet
  • 2542.3 in. W x 25.63 in. D x 17 in. H
  • 26208-230 V/60 Hz/1 ph
