657-GBX564ACKold-DraftModel GBX564AC
Product specification

Kold-Draft GBX564AC 42 5/16" Full Cube Ice Machine Head - 483 lb/24 hr, Air Cooled, 208-230v/1ph

Kold-Draft GBX564AC 42 5/16" Full Cube Ice Machine Head - 483 lb/24 hr, Air Cooled, 208-230v/1ph — image 1 of 2

Image 1 of 2

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Enter a whole number from 1 to 10,000.

Adds this item to your quote list. Pricing and fulfillment details are confirmed when we quote.

The Kold-Draft GBX564AC X-Series ice machine head delivers 483 lbs of full-cube ice daily with a stackable, space-saving design. Featuring stainless steel construction, air cooling, and an LCD display, it's built for high-efficiency commercial use.

Key features

  • 01483 lbs of full-cube ice production per 24 hours (413 lbs AHRI-certified), ideal for high-volume restaurants, bars, and catering services.
  • 02Stackable X-Series design saves floor space—pair with other units or place on top of a bin for a compact footprint.
  • 03Stainless steel exterior and durable plastic top with louvers for durability and a professional, easy-to-clean appearance.
  • 04Air-cooled condenser with fan-driven cooling for energy efficiency, reducing operational costs while maintaining high performance.
  • 05Self-contained design with an upside-down horizontal evaporator and water plate assembly produces crystal-clear ice, free of particulates and air, perfect for premium drinks.

Description

The Kold-Draft GBX564AC is a high-performance, air-cooled ice machine head designed for commercial kitchens and restaurants that demand reliable, clear full-cube ice production. With a daily capacity of 483 lbs (or 413 lbs AHRI-certified), this unit is perfect for high-volume establishments, including bars, hotels, and catering services. Its stainless steel exterior and durable plastic top not only enhance durability but also maintain a sleek, professional appearance. The stackable design allows you to maximize floor space, whether you're pairing it with another X-Series head or placing it atop a bin. The air-cooled condenser, combined with fan-driven cooling, ensures energy efficiency while the self-contained design simplifies maintenance. An upside-down horizontal evaporator and water plate assembly delivers crystal-clear ice, free of particulates and air, ideal for drinks meant to be sipped. The LCD display provides real-time temperature monitoring, and the unit operates quietly at 46 dBA, making it a seamless addition to any commercial kitchen. With a 3-year parts and labor warranty and a 5-year warranty on the compressor and evaporator, the GBX564AC offers long-term reliability for restaurants and foodservice businesses. Whether you need ice for cocktails, beverages, or culinary applications, this Kold-Draft ice machine head delivers consistency, efficiency, and durability for years to come.

Specifications

Manufacturer
Kold-Draft
24 Hr. Production (lb)
483
Compressor Type
Air Cooled
Depth (in)
31.1
Height (in)
17
Ice Type
Full Cube
Phase
1
Product
Ice Machine Heads
Product Type
Ice Makers & Bins
Rating
Better
Refrigerant
R404A
Series
X
Suggested Use
Commercial
Voltage
208/230
Warranty
3-year Parts & Labor 5-year Parts for Compressor & Evaporator
Water Inlet (in)
0.75
Width (in)
42.3
Weight
207.00

Details

  • 01483-lb. maximum ice production capacity
  • 02413-lb. AHRI-certified ice production capacity
  • 03Large-cube ice size: 1.25 in. x 1.25 in. x 1.25 in.
  • 04Ice type is ideal for drinks meant to be sipped
  • 05Stainless steel exterior with a plastic top and louvers
  • 06Unit can be stacked with other X-series units
  • 07LCD display shows the temperature
  • 08Air-cooled condenser coils
  • 09Self-contained condenser enables quick maintenance
  • 10Upside-down horizontal evaporator and water plate assembly produces clear full-size ice
  • 11Uses R404A refrigerant
  • 12Part of the X-Series
  • 13Corners are rounded to prevent injury
  • 146,500 average BTU; 8,750 maximum BTU
  • 15Bin sold separately
  • 16Required ambient air temperature: 45-110 degrees F
  • 17Required water temperature: 45-90 degrees F
  • 18Required water pressure: 20-100 PSIG
  • 19Requires clearance for ventilation and utility connections
  • 203⁄4-in. FPT potable water inlet
  • 213⁄4-in. FPT bin drain
  • 223⁄4-in. I.D. flex tubing cuber drain
  • 233⁄8-in. FPT condenser inlet
  • 241⁄2-in. FPT condenser outlet
  • 2542.3 in. W x 31.1 in. D x 17 in. H
  • 26208-230 V/60 Hz/1 ph
