Structural Concepts NR7247RSV 71 3/4" Reveal® Full Service Bakery Case w/ Straight Glass - (3) Levels, 110-120v — image 1 of 1
529-NR7247RSVStructural Concepts
Product specification

Structural Concepts NR7247RSV 71 3/4" Reveal® Full Service Bakery Case w/ Straight Glass - (3) Levels, 110-120v

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Adds this item to your quote list. Pricing and fulfillment details are confirmed after review. No order or payment is created.

The Structural Concepts NR7247RSV is a premium 3-level straight glass bakery display case with full service access, LED lighting, and a compact 32.5-inch depth—perfect for refrigerated bakery merchandising in tight spaces.

Key features

  • 013-level straight glass front with frameless UV-bonded panels for unobstructed visibility and premium aesthetic
  • 02Full-service access with 32.5-inch depth and 7.5-inch rear clearance, ideal for tight commercial spaces
  • 03LED shelf lighting (3500K frosted) enhances product presentation with even, glare-free illumination
  • 04One-piece ABS plastic tub interior and sliding rear doors for durability and easy maintenance
  • 05Eco-friendly R290 refrigerant, 110-120V compatible, and black Silversan finish for a professional look

Description

Elevate your bakery display with the Structural Concepts NR7247RSV Reveal® 3-level straight glass bakery case, designed for sleek, high-impact refrigerated merchandising. This full-service display balances functionality and aesthetics, featuring a sleek black Silversan finish, vertical frameless glass panels, and crisp LED shelf lighting (3500K frosted) to highlight your unpackaged products with clarity. The 32.5-inch counter depth and 7.5-inch rear clearance make it an ideal solution for compact retail spaces, such as convenience stores, supermarkets, or bakeries, where accessibility and visibility are paramount. With adjustable glass shelves on 1-inch centers, this bakery case ensures organized, professional presentation while accommodating a variety of product heights. Built for durability, the one-piece ABS plastic tub interior and UV-bonded glass panels resist wear, while the sliding rear doors provide easy access for stocking and cleaning. Powered by eco-friendly R290 refrigerant and compatible with 110-120V, this bakery display is a smart investment for restaurants and retailers seeking a balance of performance, energy efficiency, and style. Whether you're outfitting a high-traffic bakery section or a display in a café, this case delivers premium functionality without compromising on design.

Specifications

Manufacturer
Structural Concepts
Access
Full Service
Color
Black
Depth (in)
33
Design
Straight
Door Type
Sliding
Height (in)
47.25
Hertz
60
NEMA
L5-15P
Number of Levels
3
Phase
1
Product
Bakery Display Cases
Product Type
Commercial Refrigeration
Rating
Better
Refrigerant
R290 (Hydrocarbon)
Refrigeration Type
Refrigerated
Series
Reveal®
Shelving Type
Glass
Special Features
LED Lighting
Voltage
110/120
Warranty
1-year Limited Parts & Labor 5-year Compressor
Width (in)
71.75
Weight
1150.00

Details

  • 01Straight-glass front configuration
  • 02For unpackaged refrigerated products
  • 033 glass display levels
  • 04Freestanding design with full end panels
  • 05Adjustable on 1-in. centers clear glass shelves
  • 06Vertical, fixed front and side UV-bonded frameless glass panels
  • 07One-piece ABS plastic tub interior
  • 08Clear glass rear sliding doors
  • 09LED top and shelf lighting (3500 K frosted lens)
  • 10Black powder-coated Silversan finish
  • 11Adjustable locking casters installed
  • 123 1⁄2-in. deep, 4-in. tall recessed base section
  • 1332 1⁄2-in. counter depth
  • 1431 1⁄2-in. front-to-back case span
  • 157 1⁄2-in. minimum rear access clearance
  • 16Breeze-E (Type II) self-contained refrigeration system
  • 17R290 hydrocarbon
  • 18Fin-tube evaporator ensures uniform temperature control
  • 19Front exhaust airflow
  • 20Built-in condensate pan
  • 21Coated evaporator coil resists corrosion
  • 22Maintains 40 degrees F average product temperature
  • 23Operates under 80 degrees F / 55% RH conditions
  • 24Overall: 71 3⁄4 in. W × 33 in. D × 47 1⁄4 in. H
  • 2515.48 A, 1.54 kW
  • 26110–120 V / 60 Hz / 1 ph, 10-ft straight-blade cord with NEMA 5-15P or L5-15P plug
