440-KM1100MAJ50HoshizakiModel KM-1100MAJ50
Hoshizaki KM-1100MAJ50 30" Crescent Cube Ice Machine Head - 1023 lb/24 hr, Air Cooled, 220-240v/1ph
Request pricingIn stock
Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.
Adds this item to your quote list. Pricing and fulfillment details are confirmed after review. No order or payment is created.
The Hoshizaki KM-1100MAJ50 delivers 1023 lbs of crescent cube ice daily with air cooling and H-GUARD Plus® antimicrobial coating. Perfect for high-demand commercial kitchens, this reliable ice machine head is built for efficiency and durability.
Key features
- 01Delivers **1023 lbs of crescent cube ice per 24 hours**—perfect for high-volume commercial kitchens and restaurants.
- 02Air-cooled design with **H-GUARD Plus® antimicrobial coating** to reduce germ spread and improve hygiene in shared environments.
- 03**EverCheck™ alert system** proactively notifies staff of maintenance needs, minimizing downtime and guesswork.
- 04Stainless steel construction with **785-lb AHRI-certified ice production** and **CycleSaver™ design** for energy efficiency.
- 05Backed by a **5-year warranty on the evaporator, compressor, and condenser**—one of the longest in the industry for peace of mind.
Description
The **Hoshizaki KM-1100MAJ50 30" Crescent Cube Ice Machine Head** is a high-performance, air-cooled solution designed for commercial kitchens and restaurants that demand **1023 lbs of ice per 24 hours**. Whether you're running a bustling fast-casual spot, a fine-dining establishment, or a high-volume bar, this ice machine head ensures **consistent, high-quality crescent cube ice** without compromising on hygiene or efficiency. Its **H-GUARD Plus® antimicrobial coating** inhibits bacterial growth, making it a critical upgrade for environments with high employee turnover or frequent surface contact—ideal for reducing cross-contamination risks in shared equipment. With a **5-year warranty on the evaporator, compressor, and condenser**, this model offers long-term reliability, making it a smart investment for businesses prioritizing durability and performance.
Specifications
- Manufacturer
- Hoshizaki
- 24 Hr. Production (lb)
- 1023
- Compressor Type
- Air Cooled
- Depth (in)
- 27.38
- Height (in)
- 32.5
- Ice Type
- Crescent Cube
- Phase
- 1
- Product
- Ice Machine Heads
- Product Type
- Ice Makers & Bins
- Rating
- Best
- Refrigerant
- R404A
- Series
- KM EDGE
- Suggested Use
- Commercial
- Voltage
- 220/240
- Warranty
- 3-year Parts & Labor 5-year Evaporator Parts & Labor 5-year Compressor & Condenser Parts
- Water Inlet (in)
- 0.5
- Width (in)
- 30
- Weight
- 290.00
Details
- 011,023-lb. maximum daily ice production
- 02785-lb. AHRI-certified daily ice production
- 03Makes crescent-cube ice
- 04Ice dimensions: 1 1⁄2 in. x 1⁄2 in. x 1 1⁄8 in.
- 05CycleSaver™ design
- 06Stainless steel evaporator and exterior
- 07Self-contained condenser is air cooled
- 08Operates with R404A refrigerant
- 09H-GUARD Plus antimicrobial reduces germ spread
- 10EverCheck alert system
- 11Removable air filters
- 12Ideal incoming air temperature: 45-100 degrees F
- 13Ideal incoming water temperature: 45-90 degrees F
- 14Ideal incoming water pressure: 10-113 PSIG
- 1512,600-BTU heat transfer capacity
- 1630 in. W x 27.36 in. D x 32.5 in. H
- 17220-240 V/50 Hz/1 ph
