159-CIM0320HWIce-O-MaticModel CIM0320HW
Product specification

Ice-O-Matic CIM0320HW 22 1/4" Elevation Series™ Half Cube Ice Machine Head - 316 lb/24 hr, Water Cooled, 115v/1ph

Ice-O-Matic CIM0320HW 22 1/4" Elevation Series™ Half Cube Ice Machine Head - 316 lb/24 hr, Water Cooled, 115v/1ph — image 1 of 9

Image 1 of 9

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Enter a whole number from 1 to 10,000.

Adds this item to your quote list. Pricing and fulfillment details are confirmed when we quote.

The Ice-O-Matic Elevation Series CIM0320HW produces 316 lbs of half-cube ice daily, ideal for commercial kitchens with limited space. Water-cooled and energy-efficient, it offers reliable performance for bars, restaurants, and hotels.

Key features

  • 01316 lbs of half-cube ice per 24 hours (274 lbs AHRI-rated) – ideal for bars, restaurants, and hotels with moderate ice demands
  • 02Water-cooled design for energy efficiency and reduced operating costs; self-contained condenser for easy installation
  • 03Dual exhaust system (top and side) prevents vent blockage, ensuring safe and compliant installation in tight spaces
  • 04Compact 22 1/4" width fits narrow commercial kitchens; 24.25" depth and 21.25" height optimize space
  • 053-year parts & labor warranty + 5-year evaporator/compressor warranty; plastic food zone reduces microbial growth for cleaner ice

Description

The Ice-O-Matic CIM0320HW is a high-performance, water-cooled ice machine designed for commercial kitchens, bars, and restaurants. Part of the Elevation Series, this 316 lb/24-hour ice machine produces half-cube ice (3/8" x 7/8" x 7/8"), perfect for cocktails, drinks, and ice buckets. Its compact 22 1/4" width makes it ideal for space-constrained environments, while the dual exhaust system ensures safe installation without vent blockage risks.

With a 3-year warranty on parts and labor and a 5-year warranty on the evaporator and compressor, this machine offers long-term reliability. The water-cooled design provides energy efficiency, reducing operating costs compared to air-cooled models. Its self-contained condenser simplifies installation, making it a practical choice for new or updated commercial kitchens. The plastic food zone further enhances hygiene by restricting microbial growth, ensuring clean ice for beverages.

Whether you're outfitting a high-end bar, a hospitality venue, or a medium-volume restaurant, the Ice-O-Matic CIM0320HW delivers consistent performance and durability. Its 115V single-phase power requirement and AHRI-certified production (274 lbs/24 hrs) meet industry standards, while the R404A refrigerant ensures optimal cooling. Upgrade your ice production with this trusted commercial-grade solution.

Specifications

Manufacturer
Ice-O-Matic
24 Hr. Production (lb)
316
Compressor Type
Water Cooled
Depth (in)
24.25
Height (in)
21.25
Ice Type
Half Cube
Phase
1
Product
Ice Machine Heads
Product Type
Ice Makers & Bins
Rating
Better
Refrigerant
R404A
Series
Elevation Series™
Suggested Use
Commercial
Voltage
115
Warranty
3-year Parts & Labor 5-year Evaporator & Compressor Parts
Water Inlet (in)
0.38
Width (in)
22.25
Weight
150.00

Details

  • 01Part of the Elevation Series™
  • 02Production capacity: 316 lbs./24 hours in ideal conditions
  • 03AHRI production capacity: 274 lbs./24 hours
  • 04Produces half-size ice cubes
  • 05Cube dimensions: 3⁄8 in. x 7⁄8 in. x 7⁄8 in.
  • 06Measures 22 1⁄4 in. wide to fit into narrow spaces
  • 07Water-cooled design
  • 08Self-contained condenser is simple to install
  • 09Dual exhaust system operates on top and side
  • 10Plastic food zone restricts microbial growth
  • 11BPA-free, snap-in components are dishwasher safe to streamline cleaning
  • 12PURE ICE® antimicrobial protection
  • 13LED smart status display and notification lights
  • 14Universal Smart Harness™ control board is built in
  • 15Streamlined 1-touch controls for sanitizing and descaling
  • 16Constructed with BPA-free plastic and recyclable components
  • 17Ideal incoming water temperature: 40-100 degrees F
  • 18Ideal ambient temperature: 50-100 degrees F
  • 19Ideal water pressure: 20-80 PSIG
  • 20Heat displacement: 4,400 BTU/hour
  • 2122 1⁄4 in. W x 24 1⁄4 in. D x 21 1⁄4 in. H
  • 22120 V/60 Hz/1 ph
  • 23Potable water inlet: 3⁄8-in. FPT
  • 24Water outlet: 3⁄4-in. FPT
  • 25Electrical connection port: 7⁄8-in. diameter
  • 26Electrical connection junction box: 7⁄8-in. diameter
  • 27Condenser water inlet: 3⁄8-in. diameter
  • 28Condenser water outlet: 1⁄2-in. diameter
  • 29Ice-O-Matic ICE0320HW
