Turbo Air TOM-72L-UF-W-3S-N 70 3/4" Horizontal Open Air Cooler w/ (3) Levels, 220v/1ph — image 1 of 1
083-TOM72LUFW3SNTurbo Air
Product specification

Turbo Air TOM-72L-UF-W-3S-N 70 3/4" Horizontal Open Air Cooler w/ (3) Levels, 220v/1ph

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Adds this item to your quote list. Pricing and fulfillment details are confirmed after review. No order or payment is created.

The Turbo Air TOM-72L-UF-W-3S is a self-contained, 3-level open air cooler with 23.4 cu. ft. capacity, ideal for restaurants. Features include automatic condenser cleaning, energy-efficient R290 refrigerant, and a night cover for temperature control.

Key features

  • 01Self-contained 220V/1-phase refrigeration system – plug in and operate, no plumbing required
  • 02Auto-cleaning condenser with fine mesh filter and rotating brush – reduces maintenance and keeps airflow efficient
  • 0323.4 cu. ft. capacity with 3 levels (stainless steel deck + 2 tiers of 4 glass shelves) – ideal for drinks and snacks
  • 04Energy-efficient R290 hydrocarbon refrigerant – environmentally friendly cooling with precise temperature control
  • 05Includes night cover, solar-powered digital thermometer, and LED lighting – enhances energy savings and visibility

Description

Upgrade your restaurant's beverage display with the **Turbo Air TOM-72L-UF-W-3S**, a **self-contained, 3-level horizontal open air cooler** designed for efficiency, performance, and durability. This **220V, 1-phase commercial refrigerator** (23.4 cu. ft. capacity) eliminates the need for plumbing, making installation quick and hassle-free. Its **auto-cleaning condenser** with a fine mesh front filter and rotating brush ensures optimal airflow, reducing maintenance while maintaining energy efficiency. The **R290 hydrocarbon refrigerant** delivers precise, environmentally friendly cooling, keeping drinks and snacks at ideal temperatures for customer satisfaction. Designed with **restaurant operations in mind**, this **commercial open air cooler** features a **stainless steel interior**, **tempered glass front**, and **LED lighting** for clear visibility, while the **perforated back wall** promotes excellent air circulation. The **digital electronic thermostat** allows for easy temperature adjustments, and the **solar-powered digital thermometer** provides real-time monitoring. For energy savings, the included **night cover** preserves temperatures overnight or during business closures, reducing power costs. With a **low-profile design**, **white exterior**, and **contemporary aesthetic**, this unit blends functionality with style, making it a perfect fit for modern cafes, bars, and quick-service restaurants. Why choose the **Turbo Air TOM-72L-UF-W-3S**? It’s built for **commercial refrigeration demands**—durable, efficient, and **Better Business Bureau (BBB)-rated**. Its **self-contained system** simplifies installation, while features like **automatic condenser cleaning** and **high-density polyurethane insulation** ensure long-term reliability. Whether you need a **beverage display for a fast-casual diner** or a **sneak peek at snacks for a café**, this **3-level open air cooler** delivers performance without compromise. **Order yours today** and experience **Turbo Air’s commitment to innovation and sustainability** in commercial refrigeration.

Specifications

Manufacturer
Turbo Air
Air Exhaust
Back
Color
White
Compressor Location
Bottom
Compressor Type
Self Contained
Depth (in)
33
Design
Horizontal
Height (in)
53.13
Hertz
60
Includes
Night Curtain
Number of Levels
3
Phase
1
Product
Open Air Merchandisers
Product Type
Commercial Refrigeration
Rating
Better
Refrigerant
R290 (Hydrocarbon)
Series
TOM Series
Service Type
Self Service
Special Features
LED Lighting
Voltage
220
Warranty
2-year Limited Parts & Labor 5-year Compressor Parts
Width (in)
70.75
Weight
854.00

Details

  • 01Horizontal, low-profile unit
  • 0223.4-cu.-ft. interior capacity
  • 033 levels: stainless steel deck with 2 tiers of 4 glass shelves
  • 04Open top and perforated interior back wall for air circulation
  • 05LED interior lighting
  • 06Transparent tempered glass front and side panels
  • 07Stainless steel interior
  • 08White exterior with contemporary design
  • 09Night cover included
  • 10Self-contained refrigeration with automatic self-cleaning condenser
  • 11Environmentally friendly R290 hydrocarbon refrigerant
  • 12High-density, foamed-in-place polyurethane insulation
  • 13Digital electronic thermostat
  • 14Digital, solar-powered thermometer
  • 15Top shelves: (2) 33 1⁄2 in. W x 10 in. D
  • 16Bottom shelves: (2) 33 1⁄2 in. W x 14 in. D
  • 17Interior: 68 3⁄8 in. W x 23 1⁄2 in. D x 25 1⁄4 in. H
  • 18Overall: 70 3⁄4 in. W x 33 in. D x 53 1⁄8 in. H
  • 1913 A, (4) 3⁄4 HP
  • 20220 V/60 Hz/1 ph, 9 7⁄8-ft. cord with NEMA 6-20P plug
