Turbo Air TOM-30LB-SP-N 28 1/8" Horizontal Open Air Cooler w/ (2) Levels, 115v — image 1 of 1
083-TOM30LBSPNTurbo Air
Product specification

Turbo Air TOM-30LB-SP-N 28 1/8" Horizontal Open Air Cooler w/ (2) Levels, 115v

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Adds this item to your quote list. Pricing and fulfillment details are confirmed after review. No order or payment is created.

The Turbo Air TOM-30LB-SP-N is a sleek, low-profile horizontal open air cooler with 2 levels, perfect for displaying meats, cheeses, and prepared foods. Its stainless steel interior and LED lighting enhance presentation while ensuring durability and easy maintenance.

Key features

  • 01Sleek, low-profile 2-level horizontal open air cooler (28 1/8" wide) with 5.1-cu.-ft. capacity—perfect for high-visibility food merchandising in grocery stores and convenience shops.
  • 02Stainless steel interior and safety-reinforced tempered glass front shield ensure durability, easy cleaning, and secure product display while maintaining full customer visibility.
  • 03Built-in LED lighting under the shelf enhances product presentation, drawing attention to meats, cheeses, salads, and snacks for increased sales.
  • 04Adjustable 5/8" bolts raise to 2 3/4" for stabilization on sloped or irregular flooring, providing flexibility in installation without sacrificing stability.
  • 05Energy-efficient R290 (hydrocarbon) refrigerant, digital temperature control with defrost, and CFC-free high-density polyurethane insulation for long-lasting performance.

Description

Elevate your grocery or convenience store’s product display with the Turbo Air TOM-30LB-SP-N horizontal open air cooler, designed for high-visibility merchandising and premium presentation. This 2-level, 28 1/8" unit features a tempered glass front shield, stainless steel interior, and LED lighting beneath the shelf to highlight your best-selling items—like packaged meats, cheeses, and salads—while maintaining a professional, low-profile aesthetic. Ideal for commercial kitchens and retail environments, this unit combines functionality with modern European-style design, making it a standout choice for businesses prioritizing both efficiency and customer appeal. The 5.1-cu.-ft. interior volume and adjustable 5/8" bolts accommodate sloped or uneven flooring, ensuring stable installation without compromising space flexibility. Whether you're outfitting a deli counter, convenience store, or supermarket, this Turbo Air open air merchandiser delivers durable performance, energy efficiency with R290 refrigerant, and easy cleaning for a hassle-free experience.

Specifications

Manufacturer
Turbo Air
Air Exhaust
Back
Color
Black
Compressor Location
Bottom
Compressor Type
Self Contained
Depth (in)
34.75
Design
Horizontal
Height (in)
46.5
Hertz
60
Number of Levels
2
Phase
1
Product
Open Air Merchandisers
Product Type
Commercial Refrigeration
Rating
Better
Refrigerant
R290 (Hydrocarbon)
Series
TOM Series
Service Type
Self Service
Special Features
LED Lighting
Voltage
115
Warranty
2-year Limited Parts & Labor 5-year Compressor Parts
Width (in)
28.13
Weight
340.00

Details

  • 01Formerly TOM-30LB-SP-N
  • 025.1-cu.-ft. interior volume
  • 03Horizontal, low-profile unit
  • 04Safety-reinforced, tempered glass front shield
  • 05Solid side panels
  • 06Stainless steel interior
  • 072 levels with 1 shelf
  • 08LED lighting beneath shelf enhances presentation
  • 09Cabinet is foamed in place with CFC-free, high-density polyurethane insulation
  • 10Digital temperature controller with defrost control
  • 11Solar-powered digital thermometer
  • 12Back guard and perforated back wall and top enhance airflow
  • 13Front air intake and rear air discharge
  • 14Simple plug-in installation
  • 15Plumbing not required
  • 165⁄8-in.-tall bolts can be raised to 2 3⁄4 in.
  • 17Should not be installed in areas exceeding 75 degrees F and 55 percent humidity
  • 18Should not be installed near HVAC vents, fans, or doorways
  • 19Self-contained configuration
  • 20Environmentally friendly R-290 hydrocarbon refrigerant
  • 21Self-cleaning condenser features fine mesh filter and rotating brush for daily, automatic dust removal
  • 22Shelf: 25 1⁄2 in. W x 10 3⁄4 in. D
  • 23Interior: 25 5⁄8 in. W x 24 in. D x 17 1⁄2 in. H
  • 24Overall: 28 1⁄8 in. W x 34 3⁄4 in. D x 46 1⁄2 in. H
  • 25115 V/60 Hz/1 ph, 4 7⁄8-ft. cord with NEMA 5-15P plug
