Hatco HWBH-11QTD 11 qt Drop In Soup Warmer w/ Thermostatic Controls, 240v/1ph — image 1 of 1
042-HWBH11QTD240HatcoModel HWBH-11QTD
Product specification

Hatco HWBH-11QTD 11 qt Drop In Soup Warmer w/ Thermostatic Controls, 240v/1ph

Request pricingIn stock

Quote-list controls are preparing. If they remain unavailable, enable JavaScript or reload this page. You can still browse product details.

Adds this item to your quote list. Pricing and fulfillment details are confirmed after review. No order or payment is created.

The Hatco HWBH-11QTD is a premium 11-quart drop-in soup warmer with thermostatic controls, perfect for buffet lines and event centers. Stainless steel construction with a drain for easy cleaning.

Key features

  • 0111-quart capacity with a 12.31-inch diameter for high-volume buffet and event service
  • 02Thermostatic controls for precise temperature management, preventing overcooking
  • 03Rust-resistant stainless steel construction with a built-in drain for effortless cleaning
  • 04Drop-in design fits standard 11 1/8 to 11 9/16-inch cutouts, with options for combustible countertops
  • 05Convertible wet or dry operation, compatible with 240V/1-phase power for versatile kitchen use

Description

The Hatco HWBH-11QTD 11 qt drop-in soup warmer is a reliable, high-performance solution for keeping soups and sauces warm in commercial kitchens, buffet lines, and event centers. Designed for seamless integration into circular countertop cutouts (11 1/8 to 11 9/16 inches in diameter), this unit features thermostatic controls for precise temperature regulation, ensuring food stays warm without overcooking. Its durable stainless steel construction resists rust and corrosion, while the included drain simplifies end-of-day cleanup, saving your staff time and effort. Whether you're outfitting a high-volume restaurant, catering to large events, or streamlining your buffet service, this 240V/1-phase warmer delivers consistent performance with minimal maintenance. The convertible operation allows for wet or dry use, making it versatile for various applications, while the EZ-locking hardware ensures secure installation. For restaurants prioritizing efficiency, durability, and professional-grade performance, the Hatco HWBH-11QTD is the ideal choice for maintaining food quality and temperature in high-demand settings.

Specifications

Manufacturer
Hatco
Capacity (qt)
11
Controls
Thermostatic
Diameter (in)
12.31
Height (in)
9.59
Hertz
60
Installation Type
Drop In
Lid Type
None
Number of Insets
1
Operation
Convertible
Phase
1
Product
Soup Warmers
Product Type
Food Bars & Buffets
Special Features
With Drain
Voltage
240
Warranty
1-year Parts & Labor 2-year Element Parts
Weight
14.00

Details

  • 01Top-mounted, drop-in, high-wattage unit
  • 02Rust-resistant stainless steel
  • 03Remote control panel
  • 04Wet or dry operation
  • 05EZ locking hardware for installation
  • 06Can be installed into a circular, non-combustible countertop cutout from 11 1⁄8-11 9⁄16-in. diameter
  • 07Minimum square, combustible countertop cutout: 13 in. W x 13 in. D
  • 08Maximum square, combustible countertop cutout: 13 1⁄4 in. W x 13 1⁄4 in. D
  • 09Control box cutout: 3 1⁄4 in. W x 3 3⁄4 in. H
  • 10Control box: 3 11⁄20 in. W x 2 in. D x 4 77⁄100 in. H
  • 11Overall: 12 5⁄16 in. dia. x 9 59⁄100 in. H
  • 12240 V/60 Hz/1 ph
